ITCO Indian Machine Tools Corporation has long cherished its journey as manufacturers, suppliers and exporters of drilling solutions where auto-feed drilling machine has been a notable development. We have mechanical and hydraulic operated machines in our automatic/ auto-feed drilling machine solutions. Even customization of both these popular models is available depending on job details provided by the customer. The machines offered are sturdy in construction with hardened and ground spindle. Also they are available both for semi automatic and automatic operation allowing to keep labour dependence to an minimum. Generally z-axis automation is provided in the auto-feed models.
The mechanical model has oil dipped gears that provides continuous lubrication besides keeping wear tear low and operating temperature under control. Spindle is provided with three feeds as per the desired operation selection. In hydraulic, while choosing for automation one has the options like automatic/ pneumatic clamping of job so as to achieve minimum values of cycle time. The skill and effort required is considerably reduced by automation and low cycle times ensure higher productivity. The parts of the machine and electrical are of standard make and use standard modules of construction.
While z axis is provided with auto feed in mechanical type, in hydraulic it is programmed into using a PLC to carry hydraulic load. Auto feed drill press or the mechanical model machine has got fully geared drive for transmission and it can achieve 9 speeds. Both machines are competitively priced and also can be customized as per job requirements with various compatible attachments available with us
ITCO All Geared Autofeed Pillar & Column Type Drilling Machine
Specifications
| Drilling Capacity In Steel | 40 |
| Drilling Capacity In Cast Iron | 45 |
| No of speeds | 9 |
| Speed range | 35-850 |
| Morse Taper In Spindle(Hardened-Ground) | MT-4 |
| Spindle Travel | 210 |
| Pillar/Column Diameter | 180 |
| Round table | 580 |
| Square table | 432×432 |
| Centre distance | 300 |
| Ram diameter | 85 |
ITCO Hydraulic Auto Feed Drilling Machine
Specifications
| Drilling capacity in steel | 25/32 mm |
| Spindle morse taper | MT-3MT-4 |
| Spindle travel | 165 mm |
| Spindle speed (8 Nos) | 80, 150, 220, 320, 580, 950, 1420, 2080 |
| Pillar Diameter | 90 mm |
| Distance spindle to column | 240 mm |
| Max distance spindle to table | 560 mm |
| Max distance spindle to base | 1065 mm |
| Table working surface | 400 x 400 mm |
| Motor | 2 HP, 1440 rpm, 3 Phase |
ITCO All Geared Drilling Machine 36mm
Specifications
| Drilling capacity in steel | 25/32 mm |
| Spindle morse taper | MT-3MT-4 |
| Spindle travel | 165 mm |
| Spindle speed (8 Nos) | 80, 150, 220, 320, 580, 950, 1420, 2080 |
| Pillar Diameter | 90 mm |
| Distance spindle to column | 240 mm |
| Max distance spindle to table | 560 mm |
| Max distance spindle to base | 1065 mm |
| Table working surface | 400 x 400 mm |
| Motor | 2 HP, 1440 rpm, 3 Phase |
